Traffic Analysis for DMZ -- SSIVS_FG501E
| System: | SSIVS_FG501E in |
| Maintainer: | |
| Description: | No-Description |
| ifType: | IEEE 802.3ad Link Aggregate (161) |
| ifName: | PALO_440 |
| Max Speed: | 2000.0 Mbits/s |
| Ip: | 192.168.254.254 (No DNS name) |
The statistics were last updated Monday, 16 June 2025 at 20:40,
at which time 'SSIVS_FG501E' had been up for 33 days, 8:49:39.
`Daily' Graph (5 Minute Average)
|
Max |
Average |
Current |
| In |
135.6 Mb/s (6.8%) |
13.4 Mb/s (0.7%) |
5800.0 kb/s (0.3%) |
| Out |
78.5 Mb/s (3.9%) |
6423.7 kb/s (0.3%) |
6402.0 kb/s (0.3%) |
`Weekly' Graph (30 Minute Average)
|
Max |
Average |
Current |
| In |
88.6 Mb/s (4.4%) |
12.0 Mb/s (0.6%) |
27.8 Mb/s (1.4%) |
| Out |
26.2 Mb/s (1.3%) |
6609.6 kb/s (0.3%) |
6950.7 kb/s (0.3%) |
`Monthly' Graph (2 Hour Average)
|
Max |
Average |
Current |
| In |
78.4 Mb/s (3.9%) |
10.5 Mb/s (0.5%) |
6756.7 kb/s (0.3%) |
| Out |
18.9 Mb/s (0.9%) |
6494.6 kb/s (0.3%) |
5969.5 kb/s (0.3%) |
`Yearly' Graph (1 Day Average)
|
Max |
Average |
Current |
| In |
33.1 Mb/s (1.7%) |
8077.0 kb/s (0.4%) |
4738.3 kb/s (0.2%) |
| Out |
29.6 Mb/s (1.5%) |
5692.7 kb/s (0.3%) |
5537.3 kb/s (0.3%) |
| GREEN ### |
Incoming Traffic in Bits per Second |
| BLUE ### |
Outgoing Traffic in Bits per Second |
